HARDWARE READY

We help develop your product

Off the shelf - just use it

Distance 0-600 meter
Coin Battery

Sensors with Sub 1GHz

Low power ARM® 32-bit Cortex®-M4 or CPU with FPU with many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



Certified sub-1 GHz, 3 frequency versions:

  • 433 MHz

  • 868 MHz

  • 915 MHz

Many sensors including 3-axis accelerometer, 3-axis magnetometer, 3-axis digital gyroscope, pressure, microphone, relative humidity, ambient light, temperature and UV sensors.

Integrating Sensor Data-Logger.

Small form factor (20x30mm), ready-to-use pre-installed with Sensors over BLE demo and coin battery on-board.

SensiNBIoT | LTE-M.png

Distance: 0-100km
Rechargeable Battery

CAT M1/NB2 + BLE + GNSS

All  in one NB2 + Cat M1 + BLE + GNSS.

Based wireless microcontroller support Bluetooth™ 5.0 and IEEE 802.15.4 wireless standards such as ZigBee3.0 and Openthread. Ultra-low-power devices ARM® 32-bit Cortex®-M4 CPU & FPU with dedicated Arm® Cortex® -M0+ and many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



Quectel BG77 is an ultra-compact LPWA module supporting LTE Cat M1, LTE Cat NB2 and integrated GNSS.

Many sensors: 3-axis Accelerometer, 3-axis Magnetometer, 3-axis digital Gyroscope, Pressure, 2*Microphone, relative Humidity & Temperature , ambient light, UV, Proximity distance and Air Quality Sensor.

Size 69x30mm with Rechargeable battery.

SensiGFOX | LoRa.png

Distance: 0-10km

Non-Rechargeable/Rechargeable Battery

LoRa + Sigfox + BLE + GPS

All in one LoRa + Sigfox + BLE + GPS + USB.

Based wireless microcontroller support Bluetooth™ 5.0 and IEEE 802.15.4 wireless standards such as ZigBee3.0 and Openthread. Ultra-low-power devices ARM® 32-bit Cortex®-M4 CPU & FPU with dedicated Arm® Cortex® -M0+ and many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



ABZ-091 LoRa® Module Pre-Programmed as salve LoRa and Sigfox Modem.

Integrated GPS ORG1410.

Many sensors: 3-axis Accelerometer, 3-axis Magnetometer, 3-axis digital Gyroscope, Pressure, 2*Microphone, relative Humidity & Temperature , ambient light, UV, Proximity distance and Air Quality Sensor.

Size 69x30mm with Rechargeable battery.

SensiBLE 1.0.png

Distance 0-100 meter
Coin Battery

Sensors with BLE 4.0

Low power ARM® 32-bit Cortex®-M4 or Cortex®-M0 CPU with FPU with many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



Certified Bluetooth® low energy master/slave network processor module, compliant with Bluetooth v4.1 or 4.2

Sensors including 3-axis accelerometer, 3-axis magnetometer, 3-axis digital gyroscope, pressure, microphone, relative humidity, ambient light UV and temperature sensors.

Integrating Sensor Data-Logger.

Small form factor (20x30mm), ready-to-use pre-installed with Sensors over BLE demo and coin battery on-board.

SensiBLE 2.png

Distance 0-100 meter
Rechargeable Battery

Sensors with BLE 4.2

Based on SPBTLE-1S Low power single core (SOC) system-on-chip with 32MHz 32-bit ARM® Cortex®-M0 CPU, and Certified Bluetooth low energy (BLE) v4.2.



Sensors including Temperature, Humidity, Accelerometer, Gyro, Magnetometer, Microphone, Pressure, Light and UV. Integrating Sensor Data-Logger.



Small form factor (17x40mm), ready-to-use of the shelf.

100mA Rechargeable battery with external power adaptor with round power jack.

Distance 0-200 meter
Rechargeable Battery

Sensors with Sub 1GHz

Low power single core (SOC) system-on-chip with 32MHz 32-bit ARM® Cortex®-M0 CPU, and Certified Bluetooth low energy (BLE) v5.0



System on Board (SoB) with Pressure, Temperature, Humidity, Accelerometer, Gyro,Magnetometer, Microphone, Light and UV sensors.



Small form factor (17x40mm), ready-to-use of the shelf ,Integrating Data-Logger equipped with 100mA Rechargeable battery via  power adaptor with round power jack.

about SensiBLE 2.1

Distance 0-100 meter
Rechargeable Battery

Sensors + BLE +  Wireless Charger

Based on BLUENRG-M2 Low power single core (SOC) system-on-chip with 32MHz 32-bit ARM® Cortex®-M0 CPU, and Certified Bluetooth low energy (BLE) v5.0



Imitate ST development kit with Pressure, Temperature, Humidity, Accelerometer, Gyro,Magnetometer, Microphone, Light and UV sensors Integrating Sensors Data-Logger.



Small form factor (17x40mm), ready-to-use of the shelf.

100mA Rechargeable battery with external power adaptor with round power jack.

SensiNBIoT | LTE-M.png

Distance: 0-100km

Non-Rechargeable/Rechargeable Battery

CAT M1/NB2 + BLE + GNSS

All  in one NB2 + Cat M1 + BLE + GNSS.

Based wireless microcontroller support Bluetooth™ 5.0 and IEEE 802.15.4 wireless standards such as ZigBee3.0 and Openthread. Ultra-low-power devices ARM® 32-bit Cortex®-M4 CPU & FPU with dedicated Arm® Cortex® -M0+ and many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



Quectel BG77 is an ultra-compact LPWA module supporting LTE Cat M1, LTE Cat NB2 and integrated GNSS.

Many sensors: 3-axis Accelerometer, 3-axis Magnetometer, 3-axis digital Gyroscope, Pressure, 2*Microphone, relative Humidity & Temperature , ambient light, UV, Proximity distance and Air Quality Sensor.

Small form factor 69x30mm, ready-to-use

Non-Rechargeable/Rechargeable battery.

SensiGFOX | LoRa.png

Distance: 0-10km

Non-Rechargeable/Rechargeable Battery

LoRa + Sigfox

All in one LoRa + Sigfox + BLE + GPS + USB.

Based wireless microcontroller support Bluetooth™ 5.0 and IEEE 802.15.4 wireless standards such as ZigBee3.0 and Openthread. Ultra-low-power devices ARM® 32-bit Cortex®-M4 CPU & FPU with dedicated Arm® Cortex® -M0+ and many serial interfaces: SPI, I2C, UART, ADC, CAN, USB and GPIO.



ABZ-091 LoRa® Module Pre-Programmed as salve LoRa and Sigfox Modem.

Integrated GPS ORG1410.

Many sensors: 3-axis Accelerometer, 3-axis Magnetometer, 3-axis digital Gyroscope, Pressure, 2*Microphone, relative Humidity & Temperature , ambient light, UV, Proximity distance and Air Quality Sensor.

Small form factor 69x30mm, ready-to-use

Non-Rechargeable/Rechargeable battery.

BLE Network Processor

External MCU with BLE Network Processor

Many external interfaces



Same STM32 Nucleo Development Boards

                   But Much Smaller

No soldering.

No components purchasing.

No hardware production plan.

Get similar functionality as such with ST Microelectronics Nucleo components, but in very small form-factor.
SensiBLE is fully compatible with STMicroelectronics STM32 Nucleo and X-Nucleo ecosystem.

same as STM32 but smaller website.png

Lowering the Barriers for Developers

Fast prototyping with development continuity to final device

SensiBLE Hardware Ready enables integration of sensors with wireless connectivity, not requiring any RF experience or expertise for transforming into the final product.
It provides a complete RF platform to deliver Sensor reading over BLE to smartphone and to the cloud in a tiny form factor. Being a certified solution optimises the time to market of the final applications.


SensiBLE Software Package

Start development from day 1

The SensiBLE software runs on the STM32L476 and includes drivers that recognize the Bluetooth Low Energy (BlueNRG-MS) and sensors (humidity, temperature, pressure, accelerometer, gyroscope, magnetometer, microphone and light).

Complete middleware to build applications using sensors (humidity, temperature, pressure, accelerometer, gyroscope, magnetometer, microphone and light).


BlueST-SDK Multi-platform library (Android™/iOS™) makes it easy to develop applications and enables easy access to the data exported by the means of the Bluetooth Low energy protocol.

SensiBLE 2.png

Single Core MCU+BLE

Rechargeable Battery



Sub 1 GHZ Network Processor

External MCU with many interfaces



Design for Wearable Application

Fast prototyping with development continuity to final device

Wearable applications require light weight, long shape and rechargeable battery. SensiBLE v2.0 using Microcontroller and BLE Module in single chip, poses a challenge to Wearable applications that requires Sensors over BLE electronic device.

examples for wearable applications:

 1. Noise exposure tracking dual-mode wearable probe

2. Personal Wearable Monitor for Measurement of Activity and Environmental Exposure

3. Activity tracker

4. Data Logger

It provides a complete RF platform to deliver Sensor reading over BLE to smartphone and to the cloud in a tiny form factor. Using certified BLE module optimises the time to market of the final applications.

SIBA-J small.png

Same ST Development Boards – But Much Smaller

No soldering.

No components purchasing.

No hardware production plan.

Get similar (and much more) functionality like with ST Development Board STEVAL-IDB007V1M, but in very small form-factor.

SensiBLE 2.0 is fully compatible with STMicroelectronics STM32 Nucleo, X-Nucleo and Cube ecosystem.

same but smaller.png

Lowering the Barriers for Developers

Fast prototyping with development continuity to final device

SensiSUB Hardware Ready enables integration of sensors with wireless connectivity, not requiring any RF experience or expertise for transforming into the final product.
It provides a complete RF platform to deliver Sensor reading over SUB 1GHz to 6LowPAN gateway and to the cloud in a tiny form factor. Being a pre-certified solution optimises the time to market of the final applications.

lowering the barriers.png

Same STM32 Nucleo Development Boards

                   But Much Smaller

No soldering.

No components purchasing.

No hardwareproduction plan.

Get similar functionality as such with ST Microelectronics Nucleo components, but in very small form-factor.
SensiSUB is fully compatible with STMicroelectronics STM32 Nucleo and X-Nucleo ecosystem.

SensiSUB Same but smaller.png
SensiGFOX | LoRa.png

Sigfox | LoRa | GPS | BLE | USB

External MCU with many interfaces

Non-Rechargeable / Rechargeable Battery



Same STM32 Nucleo Development Boards

                   But Much Smaller

No soldering.

No components purchasing.

No hardware production plan.

Get similar functionality as such with ST Microelectronics Nucleo components, but in very small form-factor.
SensiGFOX | LoRa is fully compatible with STMicroelectronics STM32 Nucleo and X-Nucleo ecosystem.

SensiLoRa 1.1 Same but smaller.png

Fast prototyping with development continuity to final device

SensiGFOX | LoRa include Sigfox + LoRa + BLE + 802.15.4 + Zigbee + Thread + USB + GPS + Sensors.

Hardware Ready enables integration of sensors with wireless connectivity, not requiring any RF experience or expertise for transforming into the final product.

SensiGFOX | LoRa v1.0 is a Long/Short Range, Low Power consumption, and secure data transmission.
It provides a complete RF platform to deliver Sensor reading in a tiny form factor. Being a pre-certified solution optimises the time to market of the final applications.

SensiLoRa v1.0 Murata_PDF_3D.png
SensiLPWAN Technical information
SensiNBIoT | LTE-M.png

NBIoT | LTE-M | BLE | 802.15.4 | Zigbee | Thread | GNSS | USB

External MCU with many interfaces

Non-Rechargeable / Rechargeable Battery



Fast prototyping with development continuity to final device

SensiNBIoT | LTE-M 1.0 include Connectivity NBIoT2 + LTE-M1 + BLE 5.0 + 802.15.4 + Zigbee + Thread + USB + GNSS.

Hardware Ready enables integration of sensors with wireless connectivity, not requiring any RF experience or expertise for transforming into the final product.

SensiNBIoT | LTE-M v1.0 is a Long/Short Range, Low Power consumption, and secure data transmission.
It provides a complete RF platform to deliver Sensor reading in a tiny form factor. Being a pre-certified solution optimises the time to market of the final applications.


 STM32 Nucleo Development Boards

                   But Much Smaller

No soldering.

No components purchasing.

No hardware production plan.

Get similar functionality as such with ST Microelectronics Nucleo components, but in very small form-factor.
SensiLoRa v2.0 is fully compatible with STMicroelectronics STM32 Nucleo and X-Nucleo ecosystem.

SensiLTE 1.0 Same but smaller.png
SensiLTE v1.0 Technical Resources
SensiGFOX | LoRa 2.0.png

Single Core MCU+Sigfox

Rechargeable Battery



Fast prototyping with development continuity to final device

Stand alone Pre-Certified  Wearable SensiGFOX | LoRa 2.0

Hardware Ready enables integration of sensors with wireless connectivity. Optimises the time to market of the final applications by transforming "Off the Shelf" module, into the final product.

SensiGFOX | LoRa v2.0 is a Long Range, Low Power consumption, and secure data transmission.
Open source code with possibility to develop Firmware.

SensiGFOX | LoRa 2.0 with names.png

Same STM32 Nucleo Development Boards

                   But Much Smaller

No soldering.

No components purchasing.

No hardware production plan.

Get similar functionality as such with ST Microelectronics Nucleo components, but in very small form-factor.
SensiGFOX | LoRa v2.0 is fully compatible with STMicroelectronics STM32 Nucleo and X-Nucleo ecosystem.

SensiLoRa 2.0 Same but smaller.jpg
SensiGFOX v2.0 Technical Resources
